Schneider Electric™ ATX3 Floating Actuator, Non-Spring, PopTop , For Use With: TAC Erie™ Zone Valves, 24 V, 3-Wire Floating, 60 Hz Maximum 2 min and 30 sec Timing, Thermoplastic, 2-1/4 Inch H x 2-3/4 Inch W x 4-1/4 Inch D
- Synchronous motor drive with spring return
- Variety of voltages available
- Mounts directly onto the body without the need for linkages or calibration
- Manual override lever on normally closed actuators
- 20 mA proportional control
- Magnetic clutch to maximize motor life and gear train
- Manual override
- Position indicator
- Connections type terminal block
- NEMA 1 housing
- Stepper motor
- Terminal block connection
Standard/Approvals: UL873
Application: Cooling and Heating
