Sporlan C-082-FM

Name: Sporlan C-082-FM
Brand: Parker Hannifin
SKU: 37708
Price: 28.09 USD
Availability: InStock

Sporlan C-082-FM Sealed Liquid Line Filter Dryer, 1/4 Inch SAE Flared Female x 1/4 Inch SAE Flared Male, 650 psi

SKU: 37708

Manufacturer part number: C-082-FM

Manufacturer:

Parker Hannifin

Please Sign In to display product price.

Out of stock. 2-3 weeks Leadtime.

Sporlan Catch-All® Liquid Line Filter Dryer, Sealed, R-12, R-134a, R-22, R-407C, R-410A R-404A, R-502 and R-507, For Use With: All CFC, HCFC and HFC Refrigerants, 1/4 Inch SAE Flared Female x 1/4 Inch SAE Flared Male, 5-5/8 Inch Cut-Out Length, 8 cu-Inch Desiccant, 650 psi, 5-5/8 Inch Overall Length, Steel, 2.62 Inch Dia

1-1/2 ton R-22 capacity

Standard/Approvals: UL Listed

Products specifications

Attribute name	Attribute value
Connection Type	1/4 Inch SAE Flared Female x 1/4 Inch SAE Flared Male
Cut Out Length	5-5/8 Inch
Desiccant Volume	8 cu-Inch
Dimensions	2.62 Inch Dia
Manufacturer	Parker Hannifin
Material	Steel
Overall Length	5-5/8 Inch
Pressure Rating	650 psi
Refrigerant Type	R-12, R-134a, R-22, R-407C, R-410A R-404A, R-502 and R-507
Series	Catch-All®
Suitable For Use With	All CFC, HCFC and HFC Refrigerants
Type	Sealed
