Sorry - this product is no longer available

Honeywell M7284C1000

Honeywell M7284C Damper Actuator, Modulating, 4 - 20 mA, Non-Spring Return, CW Rotation, 150 Inch-lb
SKU: 11072
Manufacturer part number: M7284C1000
Manufacturer:

Honeywell


Please Sign In to display product price.

Honeywell M7284C Damper Actuator, Control Signal: Modulating, 4 - 20 mA, Fail Safe Mode: Non-Spring Return, CW Rotation, 150 Inch-lb, 30 - 60 sec, 90 deg, Adjustable, Asymmetrical Stroke, Dual Ended Shaft Motor, 15 VA, 3/8 Inch Shaft, Screw Terminal, -40 to 150 deg F, Die Cast Aluminum, 6-7/16 Inch H x 5-1/2 Inch W x 7-5/16 Inch D, Includes: Transformer and Screw Terminal Adapter

  • Oil immersed motor and gear train for reliable performance and long life
  • Wiring box provides NEMA 3 weather protection
  • Adapter bracket for matching shaft height of older motors is standard with replacement motors
  • Models available with integral auxiliary switches
  • Models available with adjustable zero and span
  • Motor and circuitry operate from 24 VAC
  • Fixed torque throughout the entire voltage range
  • Foot mounting
  • Square shaft
  • NEMA 1 enclosure rating
  • 50/60 Hz frequency





Standard/Approvals: UL Listed, CSA Certified, CE EN55011, EN50082-2 Approved

Application: Control Dampers and Valves

Products specifications
Attribute nameAttribute value
Control SignalModulating, 4 - 20 mA
Dimensions6-7/16 Inch H x 5-1/2 Inch W x 7-5/16 Inch D
Electrical ConnectionScrew Terminal
Fail Safe ModeNon-Spring Return
ManufacturerHoneywell
MaterialDie Cast Aluminum
Motor TypeDual Ended Shaft
Power Consumption15 VA
Rotation AngleCW
SeriesM7284C
Shaft Size3/8 Inch
Stroke90 deg, Adjustable, Asymmetrical
Timing30 - 60 sec
Torque Rating150 Inch-lb
